10
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Supported Hardware
Supervisor Engine 720 with PFC3B
Note
• Use WS-F6K-PFC3BXL= to upgrade a WS-SUP720-3B with a PFC3BXL. WS-F6K-PFC3BXL=
includes 1 GB memory upgrades for the Supervisor Engine 720 and the MSFC3. Refer to this
publication for more information:
http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/hardware/Config_Notes/78_16220.ht
ml
• WS-SUP720-3B requires atleast 1-GB DRAM to support software version12.2(33) SRE and later
releases.
• Use MEM-SUP720-SP-1GB= for Switch Processor (SP) memory upgrade and MEM-MSFC3-1GB=
for Route Processor(RP) memory upgrade. For more information, see
http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/hardware/Config_Notes/OL_20611.h
tml
Supervisor Engine 32
Note Supervisor Engine 32 does not support this hardware:
• WS-SUP720-3B
• WS-F6K-PFC3BXL—Policy Feature Card 3BXL (PFC3BXL)
• Distributed Forwarding Cards (DFCs) (installed DFCs do not power up with a Supervisor Engine
32)
• Switch Fabric Modules
• These switching modules:
–
WS-X6704-10GE—4-port 10-Gigabit Ethernet XENPAK
–
WS-X6748-SFP—48-port Gigabit Ethernet SFP
–
WS-X6724-SFP—24-port Gigabit Ethernet SFP
–
WS-X6816-GBIC—16-port Gigabit Ethernet GBIC
–
WS-X6748-GE-TX—48-port 10/100/1000 RJ-45
• 7600-SIP-600—SPA Interface Processor-600
• Optical Services Modules (OSMs)
• CISCO7603—3-slot chassis
Product ID
(append “=” for spares)
Power
Required Product Description
Minimum
Software Version
WS-SUP720-3B
7.50 A@42 V Supervisor Engine 720 with PFC3B:
• 512-MB DRAM
• Policy Feature Card 3B (PFC3B); see the
“RSP720-3C-10GE” section on page 19
• Multilayer Switch Feature Card 3 (MSFC3):
–
512-MB DRAM
–
64-MB bootflash
12.2(33)SRA
