Cisco 7861 Administration Guide

Figure 29: Adjust the Handset Rest
Procedure
Step 1 Remove the handset from the cradle and pull the plastic tab from the handset rest.
Step 2 Rotate the tab 180 degrees.
Step 3 Hold the tab between two fingers, with the corner notches facing you.
Step 4 Line up the tab with the slot in the cradle and press the tab evenly into the slot. An extension protrudes from
the top of the rotated tab.
Step 5 Return the handset to the handset rest.
Cisco IP Phone 7800 Series Multiplatform Phones Administration Guide
116
Hardware and Accessory Installation
Adjust the Handset Rest

Cisco 7861 Specifications

General

Speakerphone	Yes
Wall Mountable	Yes
Protocols	SIP
Display	3.5-inch grayscale
PoE	Yes
Audio Codec	G.711, G.729, G.722, iLBC
Headset Port	Yes
Weight	1031 g
Line Keys	16 line keys
