4-12
Cisco Unified IP Phone 7962G and 7942G Administration Guide for Cisco Unified Communications Manager 6.1(3)
OL-17679-01
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Device Configuration Menu
An option may also display one of more of the designations or icons shown in Table 4-5.
SIP Configuration Menu (SIP Phones Only)
The SIP Configuration menu contains these sub-menus:
• SIP General Configuration Menu, page 4-13
• Line Settings Menu (SIP Phones Only), page 4-14
Ta b l e 4-4 Cisco Unified Communications Manager Server State
State Description
Active Cisco Unified Communications Manager server from which the
phone is currently receiving call-processing services.
Standby Cisco Unified Communications Manager server to which the phone
switches if the current server becomes unavailable.
Blank No current connection to this Cisco Unified Communications
Manager server.
Ta b l e 4-5 Cisco Unified Communications Manager Server Designations
Designation Description
SRST Indicates a Survivable Remote Site Telephony router capable of providing
Cisco Unified
Communications Manager functionality with a limited
feature set. This router assumes control of call processing if all other Cisco
Unified Communications Manager servers become unreachable. The SRST
Cisco Unified
Communications Manager always appears last in the list of
servers, even if it is active.
For more information, refer to Cisco Unified Communications Manager
Administration Guide.
TFTP Indicates that the phone was unable to register with a Cisco Unified
Communications Manager listed in its configuration file, and that it
registered with the TFTP server instead.
Authentication icon
Indicates that the connection to the Cisco Unified Communications
Manager is authenticated. For more information about authentication, refer
to Cisco Unified Communications Manager Security Guide.
Encrypted icon
Indicates that the connection to the Cisco Unified Communications
Manager is authenticated and encrypted. For more information about
authentication and encryption, refer to Cisco Unified
Communications
Manager Security Guide.
