Page #7 background imageLoading...
Page #7 background image
Before You Begin
Remove the hookswitch clip, if necessary (see Handset, on page 3), from the cradle area.
Procedure
Step 1
Connect the handset to the Handset port.
Step 2
Connect a headset to the Headset port.
You can add a headset later if you do not connect one now.
See Headset, on page 4 for supported headsets.
Step 3
Connect a wireless headset. You can add a wireless headset later if you do not want to connect one now.
The Cisco Unified IP Phones 7971G-GE and 7970G do not support wireless headsets.Note
See the wireless headset documentation for information.
Step 4
Connect the power supply to the Cisco DC Adapter port.
See Cisco Unified IP Phone Power.
Step 5
Connect a straight-through Ethernet cable from the switch to the 10/100/1000 SW port on the Cisco Unified
IP Phones 7975G and 7971G-GE, or to the 10/100 SW port on the Cisco Unified IP Phones 7970G, 7965G
and 7945G.
Each Cisco Unified IP Phone ships with one Ethernet cable in the box.
You can use either Category 3/5/5e/6 cabling for 10 Mbps connections, but you must use Category 5/5e/6 for
100 Mbps connections and Category 5e/6 for 1000 Mbps connections.
See Network and Access Ports, on page 3 for guidelines.
Step 6
Connect a straight-through Ethernet cable from another network device, such as a desktop computer, to the
10/100/1000 PC port on the Cisco Unified IP Phones 7975G and 7971G-GE, or to the 10/100 SW port on the
Cisco Unified IP Phones 7970G, 7965G and 7945G.
You can connect another network device later if you do not connect one now.
You can use either Category 3/5/5e/6 cabling for 10 Mbps connections, but you must use Category 5/5e/6 for
100 Mbps connections and Category 5e/6 for 1000 Mbps connections.
See Network and Access Ports, on page 3 for guidelines.
Cisco Unified IP Phone Cable Installation
See the following figure and table to connect your phone.
Cisco Unified IP Phone 7975G, 7971G-GE, 7970G, 7965G, and 7945G Administration Guide for Cisco Unified
Communications Manager 9.0 (SCCP and SIP)
7
Cisco Unified IP Phones Installation
Cisco Unified IP Phone Cable Installation
