Cisco 8865 Series Installation Guide

Installation Guide for Cisco IP Phone with Multiplatform Firmware
17
Wall Mount Your 6800 Series Phones
Wall Mount Your Phone
393680
Remove the wall bracket from the wall and
attach it to the rear panel of the phone.
3
393684
393682
4
Connect the Ethernet cable and the power adapter,
and then push the cables into the notches.
Attach the phone and wall bracket
assembly to the wall.
5

Cisco 8865 Series Specifications

General

Resolution	800 x 480 pixels
Speakerphone	Full-duplex speakerphone
Codec Support	G.711, G.722, G.729, iLBC, Opus
Audio	Wideband audio
Ethernet	10/100/1000 Mbps
USB Ports	2 USB ports
Video	720p HD video
Power	IEEE 802.3af/at Power over Ethernet (PoE)
Protocols	SIP
Headset Connector	RJ9 headset port
Security	802.1X, TLS, SRTP
Weight	1.6 kg
