Cisco 8865 Series Installation Guide

Installation Guide for Cisco IP Phone with Multiplatform Firmware
27
Wall Mount Your 8800 Series Phones
Wall Mount Your Phone
Plug in the Ethernet cable, and the power adapter
(optional).
3
Attach the assembly to the wall bracket by in-
serting the tabs of the wall brackets into the slots
on the phone bracket.
4
Remove an 8800 Phone from the Wall Mount
447347
447348
447349
3
2
1
1
2
1
2
Use a screw driver or other device to disengage the tabs.
3
Lift the phone to release it from the wall bracket.
Pull the phone toward you.

Cisco 8865 Series Specifications

General

Resolution	800 x 480 pixels
Speakerphone	Full-duplex speakerphone
Codec Support	G.711, G.722, G.729, iLBC, Opus
Audio	Wideband audio
Ethernet	10/100/1000 Mbps
USB Ports	2 USB ports
Video	720p HD video
Power	IEEE 802.3af/at Power over Ethernet (PoE)
Protocols	SIP
Headset Connector	RJ9 headset port
Security	802.1X, TLS, SRTP
Weight	1.6 kg
