Cisco 8865 Series Manual

Navigation:
Use the outer ring of the Navigation cluster to scroll through menus and to move between fields. Use
the inner Select button of the Navigation cluster to select menu items.
Figure 1.1 Navigation Cluster
Phone Screen Features:
The phone screen shows information about your phone such as directory number, active call and line
status, softkeys, speed dials, placed calls, and phone menu listings. The screen is made up of three
sections: the header row, the middle section, and the footer row.
Figure 1.2 IP Phone 8865 Screen:

Cisco 8865 Series Specifications

General

Resolution	800 x 480 pixels
Speakerphone	Full-duplex speakerphone
Codec Support	G.711, G.722, G.729, iLBC, Opus
Audio	Wideband audio
Ethernet	10/100/1000 Mbps
USB Ports	2 USB ports
Video	720p HD video
Power	IEEE 802.3af/at Power over Ethernet (PoE)
Protocols	SIP
Headset Connector	RJ9 headset port
Security	802.1X, TLS, SRTP
Weight	1.6 kg
