Cisco 890 Series User Manual

1-115
Cisco Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Cisco 860, 880, 890 Series
Figure 1-78 shows the back panel of the Cisco C891-24X/K9 ISR.
Figure 1-78 Back Panel of the Cisco C891-24X/K9 ISR
For information on installing the C891-24X/K9 ISR see the following link:
http://www.cisco.com/c/en/us/td/docs/routers/access/800/hardware/installation/guide/800HIG/installin
g.html
Hardware Features
This section provides an overview of the following hardware features for the Cisco 860 Series, 880
Series, and 890 Series ISRs. A feature summary is available at the end of this section.
• Kensington Lock
• Reset Button
• LEDs
• Memory
• USB Port
• Fan
• Power Supply
• Power over Ethernet Module
• 3G Cellular Data WAN Connectivity
• Small Form-Factor Pluggable Port
• Feature Summary
364240
SYSTEM
Cisco C891-24X
POE Enabled GE LAN
1 2 3 4 5 8 9 10 116 7
1 Console or auxiliary port 7 SFP port
2 Reset Button 8 GE WAN port
3 USB port 9 SFP port
4 PoE enabled GE LAN ports 10 System LED
5 GE LAN ports 11 Kensington security slot
6 GE WAN port

Cisco 890 Series Specifications

General

Product Type	Router
Form Factor	Desktop
USB Ports	1 x USB 2.0
Firewall	Yes
VPN Support	Yes
RAM	256 MB
Wireless	802.11n
Operating Temperature	32°F to 104°F (0°C to 40°C)
Operating Humidity	10 to 85% non-condensing
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Network / Transport Protocol	TCP/IP
Routing Protocol	OSPF, BGP, RIP-1, RIP-2, EIGRP, HSRP, VRRP
Remote Management Protocol	SNMP, Telnet, HTTP, HTTPS, SSH
Features	VPN support, firewall protection, Quality of Service (QoS), VLAN support
Encryption Algorithm	AES, 3DES, DES
