Cisco 860 Series, Cisco 880 Series, and Cisco 890 Series Integrated Services Routers Hardware Installation Guide
OL-16215-11
Chapter 1 Product Overview
Cisco 890 Series ISRs
• Security feature card (SFC) socket
• DIMM expansion socket that can accept up to 512 MB of additional memory, for a total of 768 MB
system memory in Cisco 891 and 892 series ISRs, and a total of 1 GB system memory in
Cisco 892F series ISRs
• Three reverse-polarity threaded Neill-Concelman (RP-TNC) connectors on the back panel for
non-captive dual-band WLAN antenna (wireless models only)
• Support for the AIM2-CUE-K9 and AIM2-APPRE-104-K9
• GE small-form-factor pluggable (SFP) port (Cisco 892F series ISRs only)
The following feature is located on the front panel:
• Two USB 2.0 ports
Figure 1-22 shows the front panel details of the Cisco 890 wireless router.
Figure 1-22 Front Panel of the Cisco 890 Series Wireless ISR
1 LEDs 2 USB ports
