9 Mounting and Grounding the Access Point
Cisco Aironet 1832 series access points can be mounted in several configurations – on a suspended
ceiling, on a hard ceiling or wall, on an electrical or network box, and above a suspended ceiling.
Detailed instructions on how to mount the access point is available at the following URL:
http://www.cisco.com/c/en/us/td/docs/wireless/access_point/mounting/guide/apmount.html
The standard mounting hardware supported by the AP is listed in Table 1.
Table 1 Brackets and Clips for Mounting the AP
Part Number Description
Brackets AIR-AP-BRACKET-1 Low-profile bracket
(This is the default option)
AIR-AP-BRACKET-2 Universal bracket
Clips AIR-AP-T-RAIL-R Ceiling Grid Clip (Recessed mounting)
(This is the default option)
AIR-AP-T-RAIL-F Ceiling Grid Clip (Flush mounting)
AIR-CHNL-ADAPTER Optional adapter for channel-rail ceiling grid
profile.

Cisco AIR-AP1832I K9C Series Specifications

General

Model	AIR-AP1832I-K9C
Category	Wireless Access Point
Wi-Fi Standards	802.11a/b/g/n/ac
Wi-Fi Generation	Wi-Fi 5
Wireless LAN Standard	802.11ac
Frequency Bands	2.4 GHz, 5 GHz
Antenna Type	Internal
Number of Antennas	3
USB Ports	1x USB 2.0
Ethernet Ports	1x 10/100/1000BASE-T (RJ-45)
Power Options	PoE, Power Adapter
Form Factor	Ceiling mount
Maximum Data Rate	1.3 Gbps
Operating Temperature	0°C to 40°C
Storage Temperature	-30°C to 70°C (-22°F to 158°F)
Security Features	WPA, WPA2, 802.1X
MIMO	3x3 MIMO with three spatial streams
Data Transfer Rate	Up to 867 Mbps on 5 GHz, 300 Mbps on 2.4 GHz
Dimensions	200 x 200 x 45 mm
