Cisco AIR-AP1832I K9C Series User Manual

11
8 Performing a Pre-Installation Configuration
For a Cisco Mobility Express deployment, see the Cisco Mobility Express User Guide at this URL:
http://www.cisco.com/c/en/us/td/docs/wireless/access_point/mob_exp/1/user_guide/b_ME_User_Guid
e.html
The following procedures ensure that your access point installation and initial operation go as
expected. This procedure is optional.
Note Performing a pre-installation configuration is an optional procedure. If your network
controller is properly configured, you can install your access point in its final location and
connect it to the network from there. See the “Deploying the Access Point on the Wireless
Network” section on page 20 for details.
The pre-installation configuration setup is illustrated in Figure 3.

Cisco AIR-AP1832I K9C Series Specifications

General

Model	AIR-AP1832I-K9C
Category	Wireless Access Point
Wi-Fi Standards	802.11a/b/g/n/ac
Wi-Fi Generation	Wi-Fi 5
Wireless LAN Standard	802.11ac
Frequency Bands	2.4 GHz, 5 GHz
Antenna Type	Internal
Number of Antennas	3
USB Ports	1x USB 2.0
Ethernet Ports	1x 10/100/1000BASE-T (RJ-45)
Power Options	PoE, Power Adapter
Form Factor	Ceiling mount
Maximum Data Rate	1.3 Gbps
Operating Temperature	0°C to 40°C
Storage Temperature	-30°C to 70°C (-22°F to 158°F)
Security Features	WPA, WPA2, 802.1X
MIMO	3x3 MIMO with three spatial streams
Data Transfer Rate	Up to 867 Mbps on 5 GHz, 300 Mbps on 2.4 GHz
Dimensions	200 x 200 x 45 mm
