8
5 Ports and Connectors on the AP
The 1830 series access points have an LED indicator on the face of the unit, above the Cisco logo, as
shown in Figure 1. For information on the LED scheme, see the “Access Point Status LEDs” section
on page 21.
The ports and connections on the access point are shown in Figure 2.
Figure 1 Access Point LED Indicator Position
1
LED indicator position. For information on the LED scheme, see the “Access Point Status LEDs”
section on page 21.
354089
1

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco AIR-AP1832I K9C Series and is the answer not in the manual?

Cisco AIR-AP1832I K9C Series Specifications

General IconGeneral
ModelAIR-AP1832I-K9C
CategoryWireless Access Point
Wi-Fi Standards802.11a/b/g/n/ac
Wi-Fi GenerationWi-Fi 5
Wireless LAN Standard802.11ac
Frequency Bands2.4 GHz, 5 GHz
Antenna TypeInternal
Number of Antennas3
USB Ports1x USB 2.0
Ethernet Ports1x 10/100/1000BASE-T (RJ-45)
Power OptionsPoE, Power Adapter
Form FactorCeiling mount
Maximum Data Rate1.3 Gbps
Operating Temperature0°C to 40°C
Storage Temperature-30°C to 70°C (-22°F to 158°F)
Security FeaturesWPA, WPA2, 802.1X
MIMO3x3 MIMO with three spatial streams
Data Transfer RateUp to 867 Mbps on 5 GHz, 300 Mbps on 2.4 GHz
Dimensions200 x 200 x 45 mm
