Cisco ASR 9904 - Figure 2-55 Version 1 Power Module Status Indicators; Power Module Status Indicators

2-64
Cisco ASR 9000 Series Aggregation Services Router Overview and Reference Guide
OL-17501-09
Chapter 2 Functional Description
Power System Functional Description
Power Module Status Indicators
Figure 2-55 shows the status indicators for the version 1 power module and Figure 2-56 shows the status
indicators for the version 2 power module. The indicator definitions follow the two figures.
Figure 2-55 Version 1 Power Module Status Indicators
242986
1
2
3
~
=
!
