A-6
Cisco ASR 9000 Series Aggregation Services Router Overview and Reference Guide
OL-17501-09
Appendix A Technical Specifications
Caution Be sure that the chassis configuration complies with the required power budgets. Failure to properly
verify the configuration may result in an unpredictable state if one of the power units fails. Contact your
local sales representative for assistance.
Table A-8 lists the AC electrical specifications for the Cisco ASR 9006 Router.
Table A-8 Cisco ASR 9006 Router AC Electrical Specifications
Description Value
Power modules per system Version 1 power system:
Up to three AC power modules per system
Version 2 power system:
Up to four AC power modules per system
Total AC input power per
power module
3400 VA (volt-amps) per AC power module
Rated input voltage per
power module
200–240 VAC nominal (range: 180 to 264 VAC)
220–240 VAC (UK)
Rated input line frequency
1
50/60 Hz nominal (range: 47 to 63 Hz)
50/60 Hz (UK)
Input current draw
1
15 A maximum at 200 VAC
13 A maximum at 220 to 240 VRMS (UK)
Source AC service
requirement
1
1. For each AC power supply module. Some power/chassis configurations may operate at lower current ratings than
those specified in this table. Contact your Cisco technical representative for more information.
20 A North America; 16 A international;
13 A United Kingdom
Redundancy At least two AC power modules are required for N+1 redundancy
for a fully configured system (version 1 and version 2).
