Codec C20 — The physical
interface
The front panel LEDs
The LED in front of the codec indicates the status of the
codec.
• When the LED is off the codec is Off.
• The LED flashes green during the boot up and shut down
of the codec.
• The LED pulses green when the infrared (IR) port is
activated. This will occur when the remote control is in
use.
• The LED is steady green when the codec is On, in
Standby mode or in Presentation mode.
• When the LED is red this indicates an Error has occurred.
