D14637.10 Profile C20 and Quick Set C20 Administrator Guide TC6.1, APRIL 2013. www.cisco.com — Copyright © 2010-2013 Cisco Systems, Inc. All rights reserved.
123
Cisco TelePresence System Quick Set C20 and Profiles using C20 Administrator Guide
SECURITY FEATURES
• Management through HTTPS and SSH
• IP administration password
• Menu administration password
• Disable IP services
• Network settings protection
NETWORK INTERFACES
• One LAN/Ethernet (RJ-45) 10/100/1000 Mbit
OTHER INTERFACES
• USB device for future usage
PRECISIONHD 1080P 12X CAMERA
• 1/3” CMOS
• 12 × zoom
• +15°/-25° tilt, +/- 90° pan
• 43.5° vertical field of view
• 72° horizontal field of view
• Focus distance 0.3 m–infinity
• 1920 × 1080 pixels progressive @ 60fps
• Other formats supported (configurable through
dip-switch):
• 1920 × 1080@60 Hz (HDMI only)
• 1920 × 1080@50 Hz (HDMI only)
• 1920 × 1080@30 Hz
• 1920 × 1080@25 Hz
• 1280 × 720@60 Hz
• 1280 × 720@50 Hz
• 1280 × 720@30 Hz
• 1280 × 720@25 Hz
• Automatic or manual focus/brightness/
whitebalance
• Far-end camera control
• Dual HDMI and HD-SDI output
• Upside-down mounting with automatic flipping of
PRECISIONHD 1080P 4X CAMERA
• 1/3” CMOS
• 4 × zoom
• +15°/-25° tilt, +/- 90° pan
• 43.5° vertical field of view
• 72° horizontal field of view
• Focus distance 0.3m–infinity
• 1920 × 1080 pixels progressive @ 30fps / 1280 ×
720 pixels progressive @ 60fps
• Automatic or manual focus/brightness/
whitebalance
• Far-end camera control
• Upside-down mounting with manual flipping of
Note: The early shipments of the Quick Set C20
came with an interim version of the PrecisionHD
1080p 4x camera
SYSTEM MANAgEMENT
• Support for the Cisco TelePresence Management
Suite (Cisco TMS)
• Total management through embedded SNMP,
Telnet, SSH, XML, SOAP
• Remote software upload through web server, SCP,
HTTP, HTTPS
• Remote control and on-screen menu system
DIRECTORY SERVICES
• Support for local directories (My Contacts)
• Corporate directory
• Unlimited entries using server directory supporting
LDAP and H.350 (requires Cisco TMS)
• Unlimited number for corporate directory (through
Cisco TMS)
• Received calls with date and time
• Placed calls with date and time
• Missed calls with date and time
POWER
• Auto-sensing power supply
• 100-120/200-240 VAC, 60/50 Hz
• 75 W max for codec and main camera
OPERATINg TEMPERATURE AND HUMIDITY
• 0° C to 35° C (32° F to 95° F) ambient
temperature
• 10% to 90% relative humidity (RH)
STORAgE AND TRANSPORT TEMPERATURE
• -20° C to 60° C (-4° F to 140° F) at RH 10–90%
(non-condensing)
DIMENSIONS
Codec C20:
• Length: 13.8 in. / 35.0 cm
• Height: 1.2 in. / 3.0 cm
• Depth: 5 in. / 12.7
cm
• Weight: 4 lbs / 1.8 kg
MTBF PRODUCT RELIABILITY/MTBF
The predicted reliability is expressed in the expected
random Mean Time Between Failures (MTBF) for
the electronic components based on the Power On
Hours:
Power On Hours (POH) > 69 000 hours
Useful Life Cycle > 6 years
ISO 9001 certificate is available upon request
APPROVALS
EU/EEC
• Directive 2006/95/EC (Low Voltage Directive)
- Standard EN 60950-1
• Directive 2004/108/EC (EMC Directive)
- Standard EN 55022, Class A
- Standard EN 55024
- Standard EN 61000-3-2/-3-3
• Directive 2011/65/EU (RoHS)
Warning: This is a class A product. In a domestic
environment this product may cause radio
interference in which case the user may be required
to take adequate measures.
USA
• Approved according to UL 60950-1
• Complies with FCC15B Class A
Note: This equipment has been tested and found to
comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference when the equipment
is operated in a commercial environment. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is
likely to cause harmful interference in which case the
user will be required to correct the interference at his
own expense.
Canada
• Approved according to CAN/CSA C22.2 No.
60950-1
• This Class A digital apparatus complies with
Canadian ICES-003
• Cet appareil numérique de la classe A est
conforme à la norme NMB-003 du Canada
All specifications are subject to change without notice, system specifics may vary.
All images in these materials are for representational purposes only, actual products may differ.
Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and other countries.
A listing of Cisco’s trademarks can be found at www.cisco.com/go/trademarks. Third party trademarks mentioned
are the property of their respective owners. The use of the word partner does not imply a partnership relationship
between Cisco and any other company.
March 2013
* Requires option
