CHAPTER 2

Installing the Switch

• Preparing for Installation, on page 13

• Planning a Switch Data Stack , on page 17

• Installing the Switch, on page 21

• Connecting to the StackWise Ports, on page 25

• Connecting Devices to the Ethernet Ports, on page 27

Preparing for Installation

Safety Warnings

This section includes the basic installation caution and warning statements. Read this section before you start

the installation procedure. Translations of the warning statements appear in the Regulatory Compliance and

Safety Information guide on Cisco.com.

Before working on equipment that is connected to power lines, remove jewelry (including rings, necklaces,

and watches). Metal objects will heat up when connected to power and ground and can cause serious burns

or weld the metal object to the terminals. Statement 43

Warning

Do not stack the chassis on any other equipment. If the chassis falls, it can cause severe bodily injury and

equipment damage. Statement 48

Warning

Ethernet cables must be shielded when used in a central office environment. Statement 171

Warning

Do not work on the system or connect or disconnect cables during periods of lightning activity. Statement

1001

Warning

Cisco Catalyst 9200 Series Switches Hardware Installation Guide

Questions and Answers:

Need help?

Do you have a question about the Cisco C9200L-24P-4X and is the answer not in the manual?

Cisco C9200L-24P-4X Specifications

General

Model	C9200L-24P-4X
Device Type	Switch
Enclosure Type	Rack-mountable
Ports	24 x 10/100/1000 (PoE+)
Switching Capacity	128 Gbps
Forwarding Rate	95.23 Mpps
PoE Budget	370W
Layer	Layer 3
Stacking Bandwidth	80 Gbps
RAM	4 GB
Flash Memory	4 GB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Uplink Interfaces	4 x 10 Gigabit Ethernet
MAC Address Table Size	16000 entries
Routing Protocol	OSPF, BGP, EIGRP, RIP
Remote Management Protocol	SNMP, CLI, HTTP, HTTPS, SSH
Features	Energy Efficient Ethernet, DHCP snooping, QoS, VLAN support, ACLs
Compliant Standards	IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.1x
Operating Temperature	0 to 45 °C
Operating Humidity	5% to 90% (non-condensing)
