Cisco C9200L-24P-4X User Manual

Single Access Switch
(Redundant Port Channel
Uplink)
Single Access Switch
(Single Port Channel
Uplink)
Single Access Switch
(Single Uplink)
Setting
Version 2Version 2Version 2SSH
EnabledEnabledEnabledSCP
EnabledEnabledEnabledVTY Access to Switch
EnabledEnabledEnabledService Timestamp
The following VLANs are
created:
• Default VLAN
• Data VLAN
• Voice VLAN
• Management VLAN
The following VLANs are
created:
• Default VLAN
• Data VLAN
• Voice VLAN
• Management VLAN
The following VLANs are
created:
• Default VLAN
• Data VLAN
• Voice VLAN
• Management VLAN
VLAN
Layer 3 settings
configured on the
management port, based
on Quick Setup
Layer 3 settings
configured on the
management port, based
on Quick Setup
Layer 3 settings
configured on the
management port, based
on Quick Setup
Management Interface
IPv6 host policy createdIPv6 host policy createdIPv6 host policy createdIPv6 Host Policy
Auto QoS Policy for
Access defined
Auto QoS Policy for
Access defined
Auto QoS Policy for
Access defined
QoS Policy for Downlink
Ports
QoS Policy for
Distribution created
QoS Policy for
Distribution created
QoS Policy for
Distribution created
QoS Policy for Uplink
Ports
Selected ports configured
as Port-channel in trunk
mode, set to allow all
VLANs.
Selected ports configured
as Port-channel in trunk
mode, set to allow all
VLANs.
Selected uplink interfaces
configured as trunk ports,
set to allow all VLANs
Uplink Interfaces
Downlink ports
configured in Access
mode
Downlink ports
configured in Access
mode
Downlink ports
configured in Access
mode
Downlink Interfaces
Port-channel to
distribution created
Port-channel to
distribution created
Not configuredPort-channel
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
55
Configuring the Switch
Configuring Your Device Based on a Site Profile

Cisco C9200L-24P-4X Specifications

General

Model	C9200L-24P-4X
Device Type	Switch
Enclosure Type	Rack-mountable
Ports	24 x 10/100/1000 (PoE+)
Switching Capacity	128 Gbps
Forwarding Rate	95.23 Mpps
PoE Budget	370W
Layer	Layer 3
Stacking Bandwidth	80 Gbps
RAM	4 GB
Flash Memory	4 GB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Uplink Interfaces	4 x 10 Gigabit Ethernet
MAC Address Table Size	16000 entries
Routing Protocol	OSPF, BGP, EIGRP, RIP
Remote Management Protocol	SNMP, CLI, HTTP, HTTPS, SSH
Features	Energy Efficient Ethernet, DHCP snooping, QoS, VLAN support, ACLs
Compliant Standards	IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.1x
Operating Temperature	0 to 45 °C
Operating Humidity	5% to 90% (non-condensing)
