CHAPTER 4
Installing a Power Supply Unit
• Power Supply Modules Overview, on page 39
• Finding the Power Supply Module Serial Number, on page 41
• Installation Guidelines, on page 42
• Installing or Replacing an AC Power Supply Module, on page 43
Power Supply Modules Overview
The switch chassis has two power supply slots that operates with either one active power supply module and
a redundant power supply module. You can use two AC modules or one AC module and a blank cover. The
active and redundant modules must be of the same type.
All power supply modules have internal fans. All switches ship with a blank cover in the second power supply
slot.
The main module is field replaceable and the redundant module is hot-swappable. The redundant power supply
can also be used for extra PoE power.
The following table describes the supported internal power supply modules.
Table 10: Power Supply Module Part Numbers and Descriptions
DescriptionPart Number
125W AC power supply modulePWR-C5-125WAC
600W AC power supply modulePWR-C5-600WAC
1000W AC power supply modulePWR-C5-1KWAC
Blank coverPWR-C5-BLANK
All the switches ship with a blank cover in the second power supply slot if the switches are ordered with only
one power supply module.
For information about available PoE and PoE+ requirements, see these sections the Power Supply Modules,
on page 8.
The power supply modules are autoranging units that support input voltages between 100 and 240 VAC. Each
AC power supply module has a power cord for connection to an AC power outlet. The modules use an 18-AWG
power cord.
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
39

Cisco C9200L-24P-4X Specifications

General

Model	C9200L-24P-4X
Device Type	Switch
Enclosure Type	Rack-mountable
Ports	24 x 10/100/1000 (PoE+)
Switching Capacity	128 Gbps
Forwarding Rate	95.23 Mpps
PoE Budget	370W
Layer	Layer 3
Stacking Bandwidth	80 Gbps
RAM	4 GB
Flash Memory	4 GB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Uplink Interfaces	4 x 10 Gigabit Ethernet
MAC Address Table Size	16000 entries
Routing Protocol	OSPF, BGP, EIGRP, RIP
Remote Management Protocol	SNMP, CLI, HTTP, HTTPS, SSH
Features	Energy Efficient Ethernet, DHCP snooping, QoS, VLAN support, ACLs
Compliant Standards	IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.1x
Operating Temperature	0 to 45 °C
Operating Humidity	5% to 90% (non-condensing)
