Specifications for the Power Supplies and Fans
Table 20: Power Specifications for the AC Power Supplies
Power Requirements
• PWR-C5-1KWAC: 1000 W
• PWR-C5-600WAC: 600 W
• PWR-C5-125WAC: 125 W
Maximum output power
100 to 240 VAC(autoranging) 50-60 HzInput voltage and Frequency
• PWR-C5-1KWAC: 12-6A
• PWR-C5-600WAC: 7-2.8A
• PWR-C5-125WAC: 1.6-0.7A
Input current
• PWR-C5-1KWAC: 54V @ 18.5A
• PWR-C5-600WAC: 54V @ 11.1A
• PWR-C5-125WAC: 12V @ 10.5A
Output ratings
• PWR-C5-1KWAC: 3412 BTUs per hour, 1000W
• PWR-C5-600WAC: 2047.3 BTUs per hour,
600W
• PWR-C5-125WAC: 426.5 BTUs per hour, 125W
Total output BTU
Table 21: Fan Module Environmental and Physical Specifications
Environmental Ranges
23 to 176°F (–5 to 80°C)
Operating temperature
–40 to 185°F (–40 to 85°C) up to 15,000 ft (4500 m)Storage temperature
5 to 95% (noncondensing)Relative humidity
Up to 13,000 ft (4000 m)Altitude
Physical Specification
1.62 x 1.73 x 4.24 in. (4.11 x 4.39 x 10.76 cm)
Dimensions (H x D x W)
0.48 lb (0.21 kg)Weight (for three fans)
Operating Specification
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
72
Technical Specifications
Specifications for the Power Supplies and Fans

Cisco C9200L-24P-4X Specifications

General

Model	C9200L-24P-4X
Device Type	Switch
Enclosure Type	Rack-mountable
Ports	24 x 10/100/1000 (PoE+)
Switching Capacity	128 Gbps
Forwarding Rate	95.23 Mpps
PoE Budget	370W
Layer	Layer 3
Stacking Bandwidth	80 Gbps
RAM	4 GB
Flash Memory	4 GB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Uplink Interfaces	4 x 10 Gigabit Ethernet
MAC Address Table Size	16000 entries
Routing Protocol	OSPF, BGP, EIGRP, RIP
Remote Management Protocol	SNMP, CLI, HTTP, HTTPS, SSH
Features	Energy Efficient Ethernet, DHCP snooping, QoS, VLAN support, ACLs
Compliant Standards	IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.1x
Operating Temperature	0 to 45 °C
Operating Humidity	5% to 90% (non-condensing)
