Cisco Catalyst 3550

2-11
Catalyst 3550 Multilayer Switch Hardware Installation Guide
78-11358-03
Chapter 2 Installing and Starting the Switch
Installing the Switch
Figure 2-3 Attaching Brackets for 19- and 24-Inch Racks, Rear Panel Forward
Figure 2-4 Attaching Brackets for 19- and 24-Inch Racks, Rear Panel Forward
Phillips
flat-head
screws
19" Configuration
51365
Phillips
flat-head
screws
24" Configuration
60914
