Cisco Catalyst 3550

2-15
Catalyst 3550 Multilayer Switch Hardware Installation Guide
78-11358-03
Chapter 2 Installing and Starting the Switch
Installing the Switch
Figure 2-10 Attaching Brackets for 19- and 24-Inch Racks, Rear Panel Forward
Figure 2-11 Attaching Brackets for 19- and 24-Inch Telco Racks
CONSOLE
24" Configuration
49810
Phillips
flat-head
screws
1
2
Catalyst 3550
SERIES
74036
Phillips
flat-head
screws
19" Configuration
