To install the switch chassis in the equipment rack, perform these steps:
Before You Begin
•
Read the Rack-Mounting Guidelines, on page 24.
•
Install the rack-mount shelf kit. See Installing the Rack-Mount Shelf Kit, on page 33.
Procedure
Step 1
With a person standing at each side of the chassis, insert one hand into the handhold groove and the other
hand near the back of the chassis for balance. Slowly lift the chassis. Avoid sudden twists or moves to prevent
injury.
Step 2
Rest the back end of the chassis on the edges of the rack-mount shelf kit rails and carefully slide the chassis
fully into the rack.
Step 3
Locate the rack post holes that align with the chassis L bracket holes.
If the rack post holes are prethreaded, determine if the threads are 10-32 or 12-24 and install 10 screws (five
on each side).
If the rack post holes are unthreaded, install either 10-32 or 12-24 clip or cage nuts over the rack post holes
to accept the installation screws.
Cisco Catalyst 6807-XL Switch Hardware Installation Guide
38 OL-30656-01
Installing the Switch
Rack-Mounting the Chassis
