Clip nuts or cage nuts are not included as part of the accessory kit that comes with the chassis. You
must obtain them yourself.
Note
Figure 10: Installing the Chassis in a Rack with a 17.75-inch Opening
Shelf brackets secured to the rack using two
EA screws
2Five screws on each side to secure the L bracket
ears to the rack
1
Cisco Catalyst 6807-XL Switch Hardware Installation Guide
OL-30656-01 39
Installing the Switch
Rack-Mounting the Chassis
