Cisco Catalyst 6880-X - SFP and SFP+ Transceiver Module Ports

System ID (blue beacon LED)816 SFP+ ports or 100BaseFX fiber-optic ports1
USB port (console port con0)9Four half-wide port card modular slots
1
2
USB LED10Two power supply slots
2
3
Status LED11Management port (mgmt0)4
Fan tray12USB port (disk0)5
Handle to hold chassis13Console port (RJ-45 con0)6
Reset button7
1
The chassis is delivered with blank panels where the optional port cards can be installed.
2
Power supplies that are ordered are installed in the switch. If the second power supply is not ordered, a blank panel is installed.
Related Topics
SFP and SFP+ Transceiver Module Ports, on page 3
Half-Wide Modular Slots, on page 4
Power Supply Slots, on page 6
Management Port, on page 7
USB Port Type B, on page 7
USB Type A Port, on page 7
Console Port, on page 8
System Reset Button, on page 8
Blue Beacon Switch
Fan Tray, on page 8
SFP and SFP+ Transceiver Module Ports
The chassis contain 16 ports of 10-Gigabit Ethernet SFP+ or 100BASE-FX fiber-optic transceiver modules.
All ports support 1-Gigabit SFP, 10-Gigabit SFP+, or 100BASE-FX fiber-optic SFP modules.
The ports also support Cisco Trust Security (CTS) and virtual switch link (VSL) and can operate as an Instant
Access (AI) Parent in both 1-Gigabit and 10-Gigabit modes.
The SFP and SFP+ transceiver modules provide copper or fiber-optic connections to other devices. These
transceiver modules are field-replaceable and provide the uplink interfaces when installed in an SFP module
slot. The SFP transceiver modules have LC connectors for fiber-optic connections or RJ-45 connectors for
copper connections.
For a list of supported SFP and SFP+ modules, see the switch data sheet: http://www.cisco.com/c/en/us/
products/collateral/switches/catalyst-6880-x-switch/data_sheet_c78-728228.html.
Catalyst 6880-X Switch Hardware Installation Guide
OL-30827-02 3
Product Overview
SFP and SFP+ Transceiver Module Ports
