CHAPTER 6
Replacing the Fan Tray
•
Required Tools, page 73
•
Removing the Fan Tray, page 73
•
Installing the Fan Tray, page 75
•
Checking the Installation, page 76
•
Finding the Fan Serial Number, page 77
Required Tools
You might need a flat-blade or number 2 Phillips-head screwdriver to loosen or tighten the captive installation
screws on the fan tray.
Removing the Fan Tray
The fan tray is designed to be removed and replaced while the system is operating without presenting an
electrical hazard or damage to the system.
You have 120 seconds to remove and insert of the fan-tray, under specified ambient operating temperatures.Note
The fans might still be turning when you remove the fan from the chassis. Keep fingers, screwdrivers,
and other objects away from the openings in the fan’s housing. Statement 263
Warning
Procedure
Step 1
Locate the fan tray as shown in the figure.
Catalyst 6880-X Switch Hardware Installation Guide
OL-30827-02 73
