Cisco Catalyst C9300-24T User Manual

Figure 11: Rear Panel of a Cisco Catalyst 9300L Series Switch
USB3.0 SSD port5CONSOLE (RJ-45 console port)1
Power supply modules6BEACON LED2
StackWise-320 port connectors7MGMT (RJ-45 10/100/1000 management
port)
3
--Fan modules4
Figure 12: Rear Panel of a Cisco Catalyst 9300LM Series Switch
Power supply modules4Ground connectors1
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
23
Product Overview
Rear Panel

Cisco Catalyst C9300-24T Specifications

General

Model	C9300-24T
Product Type	Switch
Form Factor	Rack-mountable
Ports	24 x 10/100/1000 Ethernet Ports
DRAM	8 GB
Flash	16 GB
Stacking Bandwidth	480 Gbps
PoE Support	No
Stacking	Yes
Input Voltage	100V to 240V AC
Operating Temperature	0 to 45°C
Operating Humidity	5% to 95% non-condensing
