Cisco Catalyst C9300-24T

Connecting to the StackPower Ports
Before you begin
Before connecting the StackPower cables, review Planning a Switch Data Stack, on page 25. Always use a
Cisco-approved StackWise cable to connect the switches. To prevent misconfiguration, the StackPower ports
on the switch are keyed and have colored bands that match the keying and bands on the StackPower cable
connectors.
Procedure
Step 1 Remove the dust covers from the StackPower cable connectors.
Step 2 Connect the end of the cable with a green band to either StackPower port on the first switch. Align the connector
correctly, and insert it into a StackPower port on the switch rear panel.
Step 3 Connect the end of the cable with the yellow band to another switch (to configure StackPower power sharing).
Step 4 Hand-tighten the captive screws to secure the StackPower cable connectors in place.
Removing and installing the StackPower cable can shorten its useful life. Do not remove and insert
the cable more often than is absolutely necessary.
Caution
Installing a Network Module in the Switch
See these sections for information on network modules:
• Installing Network Modules, on page 43
Installing and Removing SFP, SFP+ , SFP28 and QSFP+ Modules
See these sections for information on SFP, SFP, SFP28 and QSFP+ modules:
• Installing SFP, SFP+ and SFP28 Modules, on page 51
• Removing SFP, SFP+ and SFP28 Modules, on page 53
• Cisco 40-Gigabit QSFP+ Transceiver Modules Installation Note
Connecting Devices to the Ethernet Ports
• 10/100/1000 Port Connections, on page 39
• PoE+ and Cisco UPOE Port Connections, on page 39
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
38
