Cisco Catalyst C9300-24T User Manual

Mounting the Switch in a Rack
Procedure
Step 1 Use the four supplied Phillips machine screws to attach the brackets to the rack.
Step 2 Use the black Phillips machine screw to attach the cable guide to the left or right bracket.
Figure 32: Front-Mounting Position
Number-12 or number-10 Phillips machine
screws
3Phillips machine screw, black1
--Cable guide2
Figure 33: Mid-Mounting Position
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
58
Installing a Switch
Mounting the Switch in a Rack

Cisco Catalyst C9300-24T Specifications

General

Model	C9300-24T
Product Type	Switch
Form Factor	Rack-mountable
Ports	24 x 10/100/1000 Ethernet Ports
DRAM	8 GB
Flash	16 GB
Stacking Bandwidth	480 Gbps
PoE Support	No
Stacking	Yes
Input Voltage	100V to 240V AC
Operating Temperature	0 to 45°C
Operating Humidity	5% to 95% non-condensing
