APPENDIX B
Connector and Cable Specifications
• Connector Specifications, on page 99
• Console Port, on page 100
• Cables and Adapters, on page 101
Connector Specifications
10/100/1000 Ports (Including PoE)
All 10/100/1000 ports use standard RJ-45 connectors and Ethernet pinouts.
Figure 51: 10/100/1000 Port Pinouts
SFP Module Connectors
Figure 52: Duplex LC Cable Connector
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
99
