Figure 11: Rear Panel of a Cisco Catalyst 9300L Series Switch
USB3.0 SSD port5CONSOLE (RJ-45 console port)1
Power supply modules6BEACON LED2
StackWise-320 port connectors7MGMT (RJ-45 10/100/1000 management
port)
3
--Fan modules4
Figure 12: Rear Panel of a Cisco Catalyst 9300LM Series Switch
Power supply modules4Ground connectors1
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
23
Product Overview
Rear Panel

Cisco Catalyst C9300-48UXM Specifications

General

Model	C9300-48UXM
Product Type	Switch
Form Factor	Rack-mountable
PoE+	Yes
Stacking Bandwidth	480 Gbps
Flash Memory	16 GB
MAC Address Table Size	32, 000 entries
Input Voltage	100-240 VAC
Uplink Interfaces	4 x 10G SFP+
Weight	18.5 lbs
Jumbo Frame Support	Yes
VLANs	4096
Power over Ethernet (PoE)	Yes
Stacking	Yes
Operating Temperature	0 to 45°C
Operating Humidity	10 - 95% (non-condensing)
Dimensions	44.5 x 44.5 x 4.4 cm
