Cisco Catalyst C9300-48UXM User Manual

CONTENTS
Preface ix
PREFACE
Document Conventions ix
Related Documentation xi
Obtaining Documentation and Submitting a Service Request xi
Product Overview 1
CHAPTER 1
Switch Models 2
Front Panel Components 4
10/100/1000 Ports 11
PoE, PoE+, Cisco UPOE and Cisco UPOE+ Ports 11
Multigigabit Ethernet Ports 11
Management Ports 12
USB Type A and Type C Ports 13
Uplink Ports 13
LEDs 14
USB Console LED 15
System LED 15
Active LED 15
STACK LED 16
PoE LED 17
XPS LED 17
S-PWR LED 17
Port LEDs and Modes 18
Beacon LED 20
Network Module LEDs 21
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
ii
Contents

Cisco Catalyst C9300-48UXM Specifications

General

Model	C9300-48UXM
Product Type	Switch
Form Factor	Rack-mountable
PoE+	Yes
Stacking Bandwidth	480 Gbps
Flash Memory	16 GB
MAC Address Table Size	32, 000 entries
Input Voltage	100-240 VAC
Uplink Interfaces	4 x 10G SFP+
Weight	18.5 lbs
Jumbo Frame Support	Yes
VLANs	4096
Power over Ethernet (PoE)	Yes
Stacking	Yes
Operating Temperature	0 to 45°C
Operating Humidity	10 - 95% (non-condensing)
Dimensions	44.5 x 44.5 x 4.4 cm
