Cisco Catalyst C9300-48UXM User Manual

a) Stick the labels available with CAT-A-AIRFLOW kit on to each side of the switch as shown in the
following illustration. Make sure you align the holes in the labels with the screw holes in the chassis.
b) Secure the brackets to the chassis using the flat head screws provided with the bracket.
NEBS is supported only with four-point mounting.
Note
Figure 31: Attaching the NEBS-Compliant Air Vent Label to the Switch
NEBS-compliant
CAT-A-AIRFLOW kit
3Number-8 Phillips flat-head screws1
--19-inch bracket2
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
57
Installing a Switch
Attaching the Rack-Mount Brackets

Cisco Catalyst C9300-48UXM Specifications

General

Model	C9300-48UXM
Product Type	Switch
Form Factor	Rack-mountable
PoE+	Yes
Stacking Bandwidth	480 Gbps
Flash Memory	16 GB
MAC Address Table Size	32, 000 entries
Input Voltage	100-240 VAC
Uplink Interfaces	4 x 10G SFP+
Weight	18.5 lbs
Jumbo Frame Support	Yes
VLANs	4096
Power over Ethernet (PoE)	Yes
Stacking	Yes
Operating Temperature	0 to 45°C
Operating Humidity	10 - 95% (non-condensing)
Dimensions	44.5 x 44.5 x 4.4 cm
