Cisco Catalyst C9300-48UXM User Manual

Fan modules5MGMT (RJ-45 10/100/1000 management
port)
2
CONSOLE (RJ-45 console port)6StackWise-320 port connectors3
Figure 13: Rear Panel of a C9300LM-48T-4Y
Power supply modules4Ground connectors1
Fixed fans5MGMT (RJ-45 10/100/1000 management
port)
2
CONSOLE (RJ-45 console port)6StackWise-320 port connectors3
Figure 14: Rear Panel of a Cisco Catalyst 9300X Series Switch
Fan modules6USB3.0–SSD port1
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
24
Product Overview
Rear Panel

Cisco Catalyst C9300-48UXM Specifications

General

Model	C9300-48UXM
Product Type	Switch
Form Factor	Rack-mountable
PoE+	Yes
Stacking Bandwidth	480 Gbps
Flash Memory	16 GB
MAC Address Table Size	32, 000 entries
Input Voltage	100-240 VAC
Uplink Interfaces	4 x 10G SFP+
Weight	18.5 lbs
Jumbo Frame Support	Yes
VLANs	4096
Power over Ethernet (PoE)	Yes
Stacking	Yes
Operating Temperature	0 to 45°C
Operating Humidity	10 - 95% (non-condensing)
Dimensions	44.5 x 44.5 x 4.4 cm
