Figure 36: Inserting the StackWise-320 Adapter
StackWise port2StackWise-320 adapter1
Step 4 Align and insert the StackWise cable connector into the StackWise adapter in the StackWise port. Push inwards
until the spring latch locks into the slot.
Figure 37: Installing the StackWise-320 Cable in a StackWise Port
Stacking cable2StackWise-320 adapter1
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
61
Installing a Switch
Connecting a StackWise-320 Cable

Cisco Catalyst C9300-48UXM Specifications

General

Model	C9300-48UXM
Product Type	Switch
Form Factor	Rack-mountable
PoE+	Yes
Stacking Bandwidth	480 Gbps
Flash Memory	16 GB
MAC Address Table Size	32, 000 entries
Input Voltage	100-240 VAC
Uplink Interfaces	4 x 10G SFP+
Weight	18.5 lbs
Jumbo Frame Support	Yes
VLANs	4096
Power over Ethernet (PoE)	Yes
Stacking	Yes
Operating Temperature	0 to 45°C
Operating Humidity	10 - 95% (non-condensing)
Dimensions	44.5 x 44.5 x 4.4 cm
