CHAPTER 5
Pluggable Interface Modules
This section contains the following:
• Overview, on page 45
• Installation, on page 46
Overview
This section describes the equipment and the procedures for successfully installing the Cisco Pluggable
Interface Module (PIM).
Highlights of the LTE Pluggable Module are:
• All Cellular interfaces are supported through a Pluggable Module
• Micro-Sim, 3FF size. Cisco recommends Industrial Temp micro SIMs that are rated from -40C to +105C
• To ensure a reliable contact to the SIM socket, gold plated SIM cards must be used
The following graphics show examples of a Pluggable Module. In this case, the LTE Pluggable Module.
Figure 11: LTE Pluggable Module (front)
LTE-Main SMA1
GNSS SMA2
Micro USB Debug Port3
LTE-Div SMA4
