Installing the SSD Module
This section provides an overview of the SSD Module installation.
Ensure that you are using proper static discharge techniques such as a wrist strap and static mat.
Note
Ensure the device is powered down before performing any removal or installation of a module.
Caution
Perform the following steps in order in install the module.
Procedure
Step 1 Note
Ensure the device is powered off.
Remove the two screws (1) holding the cover of the SSD Module Slot and retain these screws for future use.
Refer to the following figure.
Figure 20: SSD Module Cover
Step 2 Insert the SSD module into the slot on the panel so the previously removed screws (1) align with the screw
holes (2). Refer to the following figure.
