Cisco Catalyst IR1800 Rugged Series

Figure 21: Module Placement
Step 3 After the module is properly inserted, tighten the module plate to the panel with the two screws. The screws
should be torqued to 2-3 in-lb (0.2-0.3 newton meter).
Step 4 The installation is now complete.
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
53
SSD Module
Installing the SSD Module
