Figure 22: GNSS FRU Module
Installation and Removal
The module is a FRU, but is not hot swappable. Make sure the device is powered down before replacing.
Caution
The GNSS FRU Module is installed by following these steps:
Procedure
Step 1 Remove the protective cover over the GNSS slot by removing the 2 screws (1) using a Phillips driver. Retain
these two screws for further use. Refer to the following figure.
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
56
GNSS FRU Module
Installation and Removal
