Cisco Catalyst Micro Series - Page 30

Off-the-shelfTrunking base (Hager BR7010019010)1
Off-the-shelfDevice support2
Off-the-shelfMounting bracket3
Supplied by CiscoSwitch4
Supplied by CiscoShort Centered Bezel (CMICR-BZL-S-C)5
Procedure
Step 1 Insert the switch into the mounting bracket installed on the duct.
Cisco Catalyst Micro Series Switch Hardware Installation Guide
26
Switch Installation
How to Mount the Switch in a Cable Duct with Anchor Rail
