Figure 2: Detailed Architecture of a CMICR-4PC Switch
1 G SFP uplink port5Four 1 G PoE+ downlink ports1
Micro USB console port6Mode button2
microSD memory card slot71 G Copper uplink port3
--Power adapter slot4
Hardware Features
This section describes the different hardware features supported on Cisco Catalyst Micro Series Switches.
PoE and PoE+ Ports
The PoE/PoE+ ports on the switch provide PoE+ support for devices compliant with IEEE 802.3af and IEEE
802.3at and also provide PoE support for end points such as access points, IP camera or surveillance systems,
Cisco IP Phones and so on. The PoE switch ports are Power Source equipment (PSE) capable and source
Cisco Catalyst Micro Series Switch Hardware Installation Guide
3
Product Overview
Hardware Features
