Cisco CDB-8U User Manual

Figure 1: Front Panel of a Catalyst Digital Building Series PoE/PoE+ Switch
SD card slot6Downlink PoE+ ports1
Downlink port Data and PoE LEDs7Uplink Gigabit Ethernet ports2
Uplink port data LEDs8USB micro - Type B (console) port3
System LEDs9USB Type A port4
Mode button10RJ-45 Console port5
Catalyst Digital Building Series Switch Hardware Installation Guide
3
Product Overview
Front Panel

Cisco CDB-8U Specifications

General

Brand	Cisco
Model	CDB-8U
Category	Switch
Language	English
