Cisco CDB-8U User Manual

Switch Models
Table 1: Cisco Catalyst Digital Building Series Switch Models and Description
DescriptionSoftware ImageSwitch Model
Eight Fast Ethernet downlink UPOE ports; two 1-Gigabit
Ethernet uplink ports; 545W Power Supply.
LAN LiteCDB-8U
Eight Fast Ethernet downlink PoE+ ports; two 1-Gigabit
Ethernet uplink ports; 280W Power Supply.
LAN LiteCDB-8P
Front Panel
This section describes the front panel components of a Catalyst Digital Building Series Switch.
Catalyst Digital Building Series UPOE SwitchCatalyst Digital Building Series PoE/PoE+ Switch
Eight downlink Fast Ethernet UPOE portsEight downlink Fast Ethernet PoE+ ports
Two copper uplink Gigabit Ethernet portsTwo copper uplink Gigabit Ethernet ports
Mode buttonMode button
RJ-45 console portRJ-45 console port
USB micro-Type B (console) portUSB micro-Type B (console) port
USB Type A portUSB Type A port
LEDsLEDs
SD card slotSD card slot
