Procedure
Step 1
Place the flexible mount horizontally on a flat surface.
Step 2
Align the mounting holes on the bracket to the holes on the flexible mount and attach them to the mount with
the 1/4" mounting screws supplied.
Figure 21: Attaching mounting brackets to the flexible mount
