Procedure
Step 1
Place the flexible mounts on a flat surface. Slide the four tabs at the bottom of the flexible mount into the
corresponding four slots of the other flexible mount at once. Following figures show the location of tabs and
slots on the flexible mount.
Figure 34: Tabs at the bottom of the flexible mount
Tabs1
