Chapter 7 Viewing Model Information, Status, and Statistics on the Cisco Unified IP Phone
Model Information Screen
Model Information Screen
The Model Information screen includes the options described in Table 7-1.
To display the Model Information screen, press the Settings button and then select Model Information.
To exit the Model Information screen, press the Exit softkey.
Status Menu
To display the Status menu, press the Settings button and then select Status. To exit the Status menu,
press the Exit softkey.
The Status menu includes theses options, which provide information about the phone and its operation:
• Status Messages—Displays the Status Messages screen, which shows a log of important system
messages. For more information, see the
“Status Messages Screen” section on page 7-3.
• Network Statistics—Displays the Network Statistics screen, which shows Ethernet traffic statistics.
For more information, see the
“Network Statistics Screen” section on page 7-8.
• Firmware Versions—Displays the Firmware Versions screen, which shows information about the
firmware running on the phone. For more information, see the
“Firmware Versions Screen” section
on page 7-10.
Ta b l e 7-1 Model Information Settings
Option Description To Change
Model Number Model number of the phone. Display only—cannot configure.
MAC Address MAC address of the phone. Display only—cannot configure.
Load File Identifier of the factory-installed load running
on the phone.
Display only—cannot configure.
Boot Load ID Identifier of the factory-installed load running
on the phone.
Display only—cannot configure.
Serial Number Serial number of the phone. Display only—cannot configure.
CTL File Displays the MD5 hash of the certificate trust
list (CTL) file that is installed in the phone. If
no CTL file is installed on the phone, this field
displays No. (If security is configured for the
phone, the CTL file installs automatically
when the phone reboots or resets.)
For more information about this file, refer to Cisco
Unified Communications Manager Security Guide.
MIC Indicates whether a manufacturing installed
certificate (used for the security features) is
installed on the phone or is not installed on the
phone.
For more information about how to manage the MIC
for your phone, refer to the “Using the Certificate
Authority Proxy Function” section in Cisco Unified
Communications Manager Security Guide.
LSC Indicates whether a locally significant
certificate (used for the security features) is
installed on the phone or is not installed on the
phone.
For more information about how to manage the LSC
for your phone, refer to the “Using the Certificate
Authority Proxy Function” section in Cisco Unified
Communications Manager Security Guide.
Call Control
Protocol
Indicates the call processing protocol used by
the phone.
See the “Using Cisco Unified IP Phones with Different
Protocols” section on page 2-11.
