Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Network Configuration
SW Port Configuration Speed and duplex of the switch port, where:
• A—Auto Negotiate
• 10H—10-BaseT/half duplex
• 10F—10-BaseT/full duplex
• 100H—100-BaseT/half duplex
• 100F—100-BaseT/full duplex
• No Link—No connection to the switch port
PC Port Configuration Speed and duplex of the switch port, where:
• A—Auto Negotiate
• 10H—10-BaseT/half duplex
• 10F—10-BaseT/full duplex
• 100H—100-BaseT/half duplex
• 100F—100-BaseT/full duplex
• No Link—No connection to the PC port
TFTP Server 2 Backup TFTP server that the phone uses if the primary TFTP server is unavailable.
User Locale User locale associated with the phone user. Identifies a set of detailed information to
support users, including language, font, date and time formatting, and alphanumeric
keyboard text information.
Network Locale Network locale associated with the phone user. Identifies a set of detailed information to
support the phone in a specific location, including definitions of the tones and cadences
used by the phone.
Headset Enabled Indicates whether the Headset button is enabled on the phone.
User Locale Version Version of the user locale loaded on the phone.
Network Locale Version Version of the network locale loaded on the phone.
PC Port Disabled Indicates whether the PC port on the phone is enabled or disabled.
Speaker Enabled Indicates whether the speakerphone is enabled on the phone.
GARP Enabled Indicates whether the phone learns MAC addresses from Gratuitous ARP responses.
Video Capability Enabled Indicates whether the phone can participate in video calls when connected to an
appropriately equipped PC.
Voice VLAN Enabled Indicates whether the phone allows a device attached to the PC port to access the Voice
VLAN.
Auto Line Select Indicates whether the phone shifts the call focus to incoming calls on all lines.
DSCP for Call Control DSCP IP classification for call control signaling.
DSCP for Configuration DSCP IP classification for any phone configuration transfer.
DSCP for Services DSCP IP classification for phone-based services.
Security Mode Displays the security mode that is set for the phone.
Web Access Enabled Indicates whether web access is enabled (Yes) or disabled (No) for the phone.
Table 8-2 Network Configuration Area Items (continued)
Item Description
