Cisco CRS-1 Carrier Routing System SIP and SPA Hardware Installation Guide
OL-17439-01
Chapter 3 Overview: Cisco CRS-1 Shared Port Adapters
1-Port and 3-Port Clear Channel OC-3 ATM SPA Overview
Note If you oversubscribe the SIP, and the SPA subslot is locked in the failed state, refer to the
“Troubleshooting the SPA” section on page 7-2 for instructions on how to enable the SPA.
1-Port and 3-Port Clear Channel OC-3 ATM SPA Overview
The 1-Port and 3-Port Clear Channel OC-3 ATM SPA is a single-height SPA that installs into one SIP
subslot. The Clear Channel OC-3 ATM SPA with small form-factor pluggable (SFP) optical transceiver
modules provides SONET and SDH network connectivity with a per-port bandwidth of 155.52 Mbps.
For more information about SPA bandwidth, see the “Bandwidth Oversubscription” section in this
chapter.
The following sections describe the 1-Port and 3-Port Clear Channel OC-3 ATM SPA:
• 1-Port and 3-Port Clear Channel OC-3 ATM SPA LEDs, page 3-4
• 1-Port and 3-Port Clear Channel OC-3 ATM SPA Interface Specifications, page 3-5
• 1-Port and 3-Port Clear Channel OC-3 ATM SPA Cables and Connectors, page 3-5
1-Port and 3-Port Clear Channel OC-3 ATM SPA LEDs
The 1-Port and 3-Port Clear Channel OC-3 ATM SPA has three types of LEDs. There are two LEDs for
each port on the SPA, and one STATUS LED. Figure 3-2 sho
ws an example of these LEDs on a 3-Port
Clear Channel OC-3 ATM SPA.
2-Port OC-48c/STM-16 POS/RPR SPA 2.488 Gbps 2 5 Gbps
4-Port OC-48c/STM-16 POS/RPR SPA 2.488 Gbps 4 10 Gbps
1-Port OC-192c/STM-64 POS/RPR XFP SPA 10 Gbps 1 10 Gbps
1-Port OC-192c/STM-64 POS/RPR VSR Optics SPA 10 Gbps 1 10 Gbps
5-Port Gigabit Ethernet SPA 1 Gbps 5 5 Gbps
8-Port Gigabit Ethernet SPA 1 Gbps 8 8 Gbps
10-Port Gigabit Ethernet SPA 1 Gbps 10 10 Gbps
1-Port 10-Gigabit Ethernet SPA 10 Gbps 1 10 Gbps
2-Port Clear Channel T3/E3 SPA 44.736 Mbps (T3)
34.368 Mbps (E3)
2 89.47 Mbps (T3)
68.74 Mbps (E3)
4-Port Clear Channel T3/E3 SPA 44.736 Mbps (T3)
34.368 Mbps (E3)
4 178.94 Mbps (T3)
137.47 Mbps (E3)
1. Total bandwidth value assumes eight OC-12c/STM-4 optics modules.
Table 3-2 SPA Bandwidth Capacity (continued)
SPA Per-Port Bandwidth Number of Ports Total Bandwidth
