Chapter 3 Overview: Cisco CRS-1 Shared Port Adapters
10-Port Gigabit Ethernet SPA Overview
Table 3-23 describes the 10-Port Gigabit Ethernet SPA LEDs.
10-Port Gigabit Ethernet SPA Cables and Connectors
The 10-Port Gigabit Ethernet SPA has ten electrical connectors that support SFP modules. Each port can
send and receive traffic using cabling appropriate for the SFP module inserted.
SFP Module Connections
The small form-factor pluggable (SFP) module is an input/output (I/O) device that plugs into the Gigabit
Ethernet optical slots on the 10-Port Gigabit Ethernet SPA, linking the port with a 1000BASE-X
fiber-optic network.
Note The 10-Port Gigabit Ethernet SPA accepts only the SFP modules listed as supported in this document.
An SFP module check is run every time an SFP is inserted into the 10-Port Gigabit Ethernet SPA, and
only SFP modules that pass this check can be used by the 10-Port Gigabit Ethernet SPA.
SFP modules exist for technologies other than Gi
gabit Ethernet and for products other than the 10-Port
Gigabit Ethernet SPA. However, the information in this document pertains only to SFP modules that plug
into the 10-Port Gigabit Ethernet SPA ports.
The SFP module has a receiver port (RX) and a transmitter port (TX) that compose one optical interface.
Table 3-24 and Ta
ble 3-25 provide SFP information and specifications.
Ta b l e 3-23 10-Port Gigabit Ethernet SPA LEDs
LED Label Color State Meaning
A/L Off Off Port is not enabled.
Green On Port is enabled and the link is up.
Amber On Port is enabled and the link is down.
STATUS Off Off SPA power is off.
Green On SPA is ready and operational.
Amber On SPA power is on and good, and the SPA is being
conf
igured.
Ta b l e 3-24 10-Port Gigabit Ethernet SFP Module Options
SFP Module
Product Number SFP Module Description
SFP-GE-S Short wavelength
(
1000BASE-SX)
Contains a Class 1 laser of 850 nm for
1000BASE-SX (short-wavelength) applications.
SFP-GE-L Long wavelength/long haul
(
1000BASE-LX/LH)
Contains a Class 1 laser of 1310 nm for
1000BASE-LX/LH (long-wavelength)
applications.
SFP-GE-Z Extended wavelength
(
1000BASE-ZX)
Contains a Class 1 laser of 1550 nm for
1000BASE-ZX (extended-wavelength)
applications.
