Figure 8: Status LEDs
Power, Status, and Active LEDs on top of chassis2Power, Status, and Active LEDs on rear of chassis1
The following figure shows all of the LEDs on the rear panel of the Firepower 1010 and describes their states.
Figure 9: Rear Panel LEDs
Cisco Firepower 1010 Hardware Installation Guide
9
Overview
Status LEDs
